Two AC outputs
The main output has a no-break functionality for computers and other electronic equipment that allows less than 20 milliseconds delay. Therefore, no disruption while taking over the supply to the connected devices.
The second output is live only when AC is available for the MultiPlus, preventing the loads from discharging the battery, such as the water heater.
Parallel operation capability to provide virtually unlimited power.
Up to 6 MultiPluses can operate parallel providing 15kW/18kVA output power with 420 amps of charging capacity.
Three-phase power supply capability (3 units are required)
PowerControl – Dealing with limited generator, shore side, or grid power.
MultiPlus is an immensely powerful battery charger, with the Multi-Control panel a maximum generator or shore current can be set therefore MultiPlus by taking account of other AC loads will only use the excess for the battery charging thus preventing the overload of generator or shore.
PowerAssist – Boosting the capacity of the shore or generator.
MultiPlus taking principles of PowerControl to another dimension will be able to supplement the capacity of the alternative source. Where peak power is required only for a limited period the MultiPlus will make sure that insufficient sore or generator power is compensated for by power from the battery.
Four-stage adaptive charger and dual bank battery charging
The main output provides a powerful charge to the battery system utilizing ‘Adaptive Charge’ software. The software automatically fine-tunes the 3-stage process to suit battery condition and then adds a fourth stage for long periods of float charging. The adaptive charge process is better described on our Phoenix Chargers.
Easier system configuration
After installation, the system is ready to go and if something needs to change, it is possible with the DIP switch setting in few minutes.
Remote configuring and Controlling.
When connected to the Ethernet, systems with a Color Control GX or other GX device can be accessed and settings can be changed remotely.
Brand: Victron Energy
Height-1: 50.6 inches
Length-1: 14.7 inches
Width-1: 27.5 inches
